MONOCHROM-L CCT Controller
0002-1-CON-L-20
- Low stock - 3 items left
- Backordered, shipping soon
The Monochrom-L (Large) controller is the step up from its little brother, handling bigger loads (up to 360W @ 24V) while still delivering smooth, flicker-free dimming. Ideal for longer runs, larger areas, or jobs where one controller needs to do more, as older brothers usually do.
It pairs with our Monochrom remote for wireless control, or can be hardwired to a standard wall switch for simple on/off operation. Easy to set up, reliable in performance, and built to handle more demanding installs without complications.
|
Input Voltage (VDC) |
12-48VDC |
|
Input Current (A) |
|
|
Output Voltage (VDC) |
12-48VDC |
|
Output Current |
15A @ 12/24VDC |
|
Output Power (W) |
12V = 180W |
|
Output Type |
Constant Voltage |
|
Input Signal |
RF 2.4GHz + Push Dim |
|
Control Distance |
30m (Barrier Free Space) |
|
Dimming Gray Scale |
4096 (2^12) levels |
|
Dimming range |
0-100% |
|
Dimming Curve |
Logarithmic |
|
PWM Frequency |
500Hz (default) |
|
Operation Temperature |
-20°C ~ +55°C |
|
Case Temperature (Max) |
+85°C |
|
IP Rating |
IP20 |
|
Warranty |
60 months from date of purchase |
|
Protection |
Reverse polarity |
|
Additonal Notes |
The output power of a constant voltage power supply should be at least 1.2 times that of the output load (light strip), otherwise the full power output of the load can easily cause automatic flickering or shaking of the light. |
